Cross tab

Cross tabulation , is defined on WikiPedia as A cross tabulation (often abbreviated as cross tab) displays the joint distribution of two or more variables.

As below figures, the column values of the first table is transformed to column names in the second one, so the production of





Cross tabs are frequently used because:

1. They are easy to understand. They appeal to people who do not want to use more sophisticated measures.
2. They can be used with any level of data: nominal, ordinal, interval, or ratio - cross tabs treat all data as if it is nominal.
3. A table can provide greater insight than single statistics.
4. It solves the problem of empty or sparse cells.
5. They are simple to conduct.



I think the cross-tab is really what the Relational Database means. That’s a meaningful “Relationships” between entities but not entity and it’s attributes.

Solution by SQL Server 2005

Code:

SELECT
    SalesPerson,
    [Oranges] AS Oranges,
    [Pickles] AS Pickles
FROM
    ( SELECT SalesPerson, Product, SalesAmount FROM tblSales ) ps
PIVOT
    (
      SUM (SalesAmount)
      FOR Product IN ( [Oranges], [Pickles])
    ) AS pvt



This most weak part of feature is that you must list all pivot column name manually. It’s pain.

BOL: Using PIVOT and UNPIVOT

SELECT < non-pivoted column>,
    [first pivoted column] AS ,
    [second pivoted column] AS ,
    ...
    [last pivoted column] AS
FROM
    (< SELECT query that produces the data>)
    AS
PIVOT
(
    < aggregation function>()
FOR
[< column that contains the values that will become column headers>]
    IN ( [first pivoted column], [second pivoted column],
    ... [last pivoted column])
) AS
< optional ORDER BY clause>;

Solution by MS Access

Microsoft Access provides a very nice cross table design wizard.

With the wizard, we get the cross-tab script based on JET-SQL.

TRANSFORM Sum(tblSales.SalesAmount) AS [Sum of SalesAmount]
SELECT tblSales.SalesPerson, Sum(tblSales.SalesAmount) AS [Total SalesAmount]
FROM tblSales
GROUP BY tblSales.SalesPerson
PIVOT tblSales.Product;

Pivot columns is automaticly generated and the aggregation over all pivot column can be produced. The JET-SQL is so smart and smoothly for small applications those don’t have to be scaled. You can use almost all VBA programming utilities in it. The TRANSFORM/PIVOT feature is powerful and more then 5 years before the SQL Server’s implementation.

It is based on JET-SQL, so not availible in an ADP project.

Solution by SQL Server 2000, CASE and GROUP

The classic solution of cross-tab in SQL Server 2000 or before is produced by CASE and GROUP.

select
    SalesPerson,
    SUM(CASE Product WHEN 'Pickles' THEN SalesAmount ELSE 0 END ) as [Pickles],
    SUM(CASE Product WHEN 'Oranges' THEN SalesAmount ELSE 0 END ) as [Oranges],
    SUM(SalesAmount)    as [Total Sales]
from
    tblSales
group by
    SalesPerson

We can find it’s footprint clearly in the SQL Server 2005’s pivot feature. And this is a base for other ideas.

Solution by SQL Server 2000, Dynamic SQL

Dynamic Cross-Tabs/Pivot Tables By Rob Volk

Solution by Excel

But the most easy and rich tool I have used is MS Excel’s pivot table.

Pivot table and OLAP Cube

The basic idea of OLAP Cube is a multi-dimession pivot table. The common visualization tool for OLAP is also a pivot table or pivot chart viewer.

So, draw a figure to show basic concepts in OLAP by example metioned above as the END.
